Google Cloud

This directory contains all Google Cloud deployment options for the Zscaler MCP Server.

Video Walkthrough

End-to-end walkthrough covering every Google Cloud deployment option in this guide — Cloud Run, GKE, Compute Engine VM, and the ADK Agent (local + Cloud Run). Click the thumbnail to watch on Wistia, or jump to a per-target walkthrough below:

Target	Walkthrough
Google Cloud Run	Watch on Wistia
Google Kubernetes Engine (GKE)	Watch on Wistia
Google ADK Agent (Cloud Run)	Watch on Wistia

What's Included

integrations/google/
├── README.md                       # This file
├── gcp/                            # Standalone MCP server deployment
│   ├── gcp_mcp_operations.py       # Unified deployment script (Cloud Run, GKE, Compute Engine VM)
│   └── env.properties              # Template .env file
└── adk/                            # Google ADK agent integration (separate product)
    ├── adk_agent_operations.py     # ADK agent operations (local, Cloud Run, Agent Engine, Agentspace)
    ├── README.md
    └── zscaler_agent/              # ADK agent source code

Deployment Options

Option 1: Standalone MCP Server (gcp/gcp_mcp_operations.py)

Interactive deployment of the Zscaler MCP Server as an independent service. Supports three targets:

Target	What It Deploys	Runtime
Cloud Run	Docker container (managed, serverless)	zscaler/zscaler-mcp-server:latest (Docker Hub)
GKE	Docker container on self-managed or Autopilot cluster	Same image; optionally creates a new Autopilot cluster
Compute Engine VM	Python library from PyPI via systemd	pip install zscaler-mcp[gcp] on Debian 12

▶ Per-target walkthroughs:

Cloud Run	GKE
Watch on Wistia	Watch on Wistia

Compute Engine VM has no dedicated walkthrough yet — see the complete walkthrough above for full coverage.

MCP clients (Claude Desktop, Cursor, etc.) connect directly to the server over HTTPS using streamable-http transport.

Quick start:

cd integrations/google/gcp
python gcp_mcp_operations.py deploy      # guided deployment (prompts for target)
python gcp_mcp_operations.py status      # check health
python gcp_mcp_operations.py logs        # stream logs
python gcp_mcp_operations.py ssh         # SSH into VM (VM only)
python gcp_mcp_operations.py destroy     # tear down
python gcp_mcp_operations.py destroy -y  # tear down (no prompt)

Features:

• Interactive CLI with numbered menus (same UX as the Azure deployment script)
• GCP Secret Manager integration (optional, recommended)
• Four auth modes: JWT, API Key, Zscaler, None
• Auto-configures Claude Desktop and Cursor client configs
• State file (.gcp-deploy-state.json) for status/logs/destroy operations

Option 2: ADK Agent (adk/adk_agent_operations.py)

Deploys a Gemini-powered AI agent that wraps the MCP server as an internal subprocess. Users interact with the agent through natural language — not directly with the MCP server.

Target	Description
Local	Run locally with adk web using GOOGLE_API_KEY
Cloud Run	Deploy agent container to Cloud Run (built from source via Cloud Build)
Agent Engine	Deploy to Vertex AI Agent Engine (fully managed)
Agentspace	Register an Agent Engine deployment with Google Agentspace

All targets are managed through a single interactive script:

cd integrations/google/adk
python adk_agent_operations.py deploy      # guided deployment (prompts for target)
python adk_agent_operations.py status      # check status
python adk_agent_operations.py logs        # stream logs
python adk_agent_operations.py destroy     # tear down

See adk/README.md for full documentation.

Option 3: Gemini CLI Extension

The Zscaler MCP Server is also available as a Gemini CLI extension for local developer use. The extension manifest (gemini-extension.json) lives at the repository root (required by Gemini CLI) and is documented in integrations/gemini-extension/README.md.

Prerequisites

• gcloud CLI installed and authenticated
• A GCP project with billing enabled
• Zscaler OneAPI credentials
• For GKE: kubectl installed (cluster can be created by the script or pre-existing)
• For ADK: Google ADK installed

Required GCP APIs

gcloud services enable \
  run.googleapis.com \
  compute.googleapis.com \
  container.googleapis.com \
  secretmanager.googleapis.com \
  artifactregistry.googleapis.com \
  aiplatform.googleapis.com \
  cloudbuild.googleapis.com \
  --project YOUR_PROJECT_ID

Required IAM Roles

The default Compute Engine service account (PROJECT_NUMBER-compute@developer.gserviceaccount.com) needs specific roles depending on the deployment type.

Standalone MCP Server

Role	Cloud Run	GKE	VM	Purpose
roles/secretmanager.secretAccessor	Yes	Yes	Yes	Read credentials from Secret Manager
roles/iam.workloadIdentityUser	—	Yes	—	Bind K8s service account to GCP service account
roles/run.invoker	Per-user	—	—	Invoke Cloud Run in enterprise orgs (see below)

ADK Agent (Cloud Run)

Role	Required	Purpose
roles/storage.admin	Yes	Cloud Build uploads source to Cloud Storage
roles/artifactregistry.writer	Yes	Cloud Build pushes container to Artifact Registry
roles/aiplatform.user	Yes	Cloud Run service calls Gemini via Vertex AI
roles/run.invoker	Per-user	Invoke Cloud Run in enterprise orgs

Quick Setup

PROJECT_ID="your-project"
PROJECT_NUMBER=$(gcloud projects describe $PROJECT_ID --format="value(projectNumber)")
SA="${PROJECT_NUMBER}-compute@developer.gserviceaccount.com"

gcloud projects add-iam-policy-binding $PROJECT_ID \
  --member="serviceAccount:$SA" --role="roles/secretmanager.secretAccessor"
gcloud projects add-iam-policy-binding $PROJECT_ID \
  --member="serviceAccount:$SA" --role="roles/storage.admin"
gcloud projects add-iam-policy-binding $PROJECT_ID \
  --member="serviceAccount:$SA" --role="roles/artifactregistry.writer"
gcloud projects add-iam-policy-binding $PROJECT_ID \
  --member="serviceAccount:$SA" --role="roles/aiplatform.user"

Configuration

Step 1: Create .env file

cd gcp
cp env.properties .env

Step 2: Edit .env

Update the values for your environment. At minimum:

GCP_PROJECT_ID=your-gcp-project
ZSCALER_CLIENT_ID=your-client-id
ZSCALER_CLIENT_SECRET=your-client-secret
ZSCALER_VANITY_DOMAIN=your-vanity-domain
ZSCALER_CUSTOMER_ID=your-customer-id

Step 3: Deploy

python gcp_mcp_operations.py deploy

The script will prompt for deployment target, auth mode, and all required options.

Enterprise Considerations

Cloud Run: GCP Organization IAM Policies

Many enterprise GCP organizations enforce the constraints/iam.allowedPolicyMemberDomains organization policy, which prevents granting allUsers or allAuthenticatedUsers access to Cloud Run services. When this policy is active, the --allow-unauthenticated flag on gcloud run deploy will silently fail, and Cloud Run's IAM layer will return 401 for all external requests — before the MCP server's own auth layer is reached.

Impact: MCP clients like Claude Desktop and Cursor use mcp-remote to connect. When mcp-remote receives a 401 from Cloud Run's IAM layer, it interprets this as an MCP OAuth challenge and enters an OAuth discovery flow, which hangs indefinitely.

Recommended patterns for enterprise environments:

Pattern	Description
Compute Engine VM	No Cloud Run IAM layer — the MCP server's own auth (JWT, API Key, Zscaler) is the sole gatekeeper. Works out of the box.
GKE	No Cloud Run IAM layer — K8s LoadBalancer exposes the service directly. MCP server auth handles access control.
Cloud Run + VPC-only ingress	Restrict Cloud Run to internal traffic only (no public endpoint). Users connect through corporate VPN/network, and the MCP server's auth layer handles application-level access.
Cloud Run + Identity-Aware Proxy (IAP)	IAP handles org-level authentication via browser login. The MCP server handles tool-level auth via its own header.
Cloud Run + gcloud run services proxy	The proxy runs locally, handles GCP IAM auth transparently, and forwards requests to Cloud Run. The MCP server's auth travels through the proxy. Suitable for developer/testing scenarios.

For PoC and testing: The Compute Engine VM option avoids this issue entirely and was validated end-to-end with zscaler auth mode.
