Microsoft Azure

Deploy the Zscaler MCP Server to Azure with your choice of deployment target, authentication mode, and Azure Key Vault for secret storage.

Video Walkthrough

End-to-end walkthrough of every deployment target in this guide — Container Apps, Virtual Machine, AKS, and the Azure AI Foundry agent. Click the thumbnail to watch on Wistia, or jump to a per-target walkthrough in the matching section below:

Target	Walkthrough
Azure Container Apps	Watch on Wistia
Azure Virtual Machine	Watch on Wistia
Azure Kubernetes Service (Preview)	Watch on Wistia
Azure AI Foundry Agent	Watch on Wistia

Deployment Targets

Target	Description	Image/Package	Status
Azure Container Apps	Managed, serverless containers	Docker Hub: `zscaler/zscaler-mcp-server:latest`	GA
Azure Virtual Machine	Ubuntu 22.04, self-managed	PyPI: `zscaler-mcp-server`	GA
Azure Kubernetes Service (AKS)	Kubernetes Deployment + LoadBalancer Service	Docker Hub: `zscaler/zscaler-mcp-server:latest`	Preview

Container Apps and VM use Azure Key Vault for secure credential storage and support all five authentication modes. AKS is in Preview: it now supports Azure Key Vault via Workload Identity Federation + the Key Vault CSI driver as the default credential storage path (with a plain env-var fallback for PoCs), and supports the jwt, api-key, zscaler, and none auth modes today. OIDCProxy auth, TLS Ingress, and HPA are still planned for AKS GA.

What It Does

The azure_mcp_operations.py script provides a fully interactive deployment experience:

Prompts for deployment target (Container Apps, VM, or AKS Preview)
Prompts for credential source (.env file or manual entry)
Collects Zscaler API credentials and MCP auth configuration
Creates Azure infrastructure (resource group, Key Vault for Container Apps/VM, AKS cluster on demand)
Stores all secrets in Azure Key Vault (Container Apps default, VM mandatory, AKS default via the Key Vault CSI driver + Workload Identity), or as plain env vars when explicitly opted in
Deploys with the selected authentication mode
Updates Claude Desktop and Cursor configs to connect remotely
Provides destroy, status, logs, and ssh (VM only) commands

Authentication Modes

Mode	Description	Client Auth Header
OIDCProxy	OAuth 2.1 + DCR via OIDC provider (browser login)	Handled automatically by `mcp-remote`
JWT	Validate JWTs against a JWKS endpoint	`Authorization: Bearer <JWT>`
API Key	Shared secret (auto-generated if not provided)	`Authorization: Bearer <api-key>`
Zscaler	Validate via OneAPI client credentials	`Authorization: Basic base64(id:secret)`
None	No authentication (development only)	No header

Prerequisites

Azure CLI (az) — logged in (az login)
Node.js — for npx mcp-remote (Claude Desktop bridge)
Zscaler OneAPI credentials (from ZIdentity console)
For OIDCProxy: an OIDC provider app registration (Entra ID, Okta, Auth0, etc.)
For VM: SSH key pair (script can generate one)

Quick Start

# Interactive guided deployment — no .env file required
python azure_mcp_operations.py deploy

# The script will prompt you for:
#   1. Deployment target (Container Apps or VM)
#   2. Credential source (.env file or manual entry)
#   3. Auth mode (OIDCProxy, JWT, API Key, Zscaler, None)
#   4. Azure options (resource group, region, Key Vault)

Operations

MCP Server Operations

Command	Description
`deploy`	Interactive guided deployment (Container Apps, VM, or AKS Preview)
`destroy`	Tear down all Azure resources (full rollback). For AKS with an existing cluster, removes only the K8s Deployment + Service.
`status`	Show deployment status and health
`logs`	Stream container/VM/pod logs
`ssh`	SSH into VM (VM deployments only)

python azure_mcp_operations.py deploy     # guided deployment
python azure_mcp_operations.py status     # check health
python azure_mcp_operations.py logs       # stream logs
python azure_mcp_operations.py ssh        # SSH into VM
python azure_mcp_operations.py destroy    # tear down everything
python azure_mcp_operations.py destroy -y # non-interactive destroy

Foundry Agent Operations

Command	Flags	Description
`agent_create`		Create a Foundry agent with Zscaler MCP tools. Prompts for project endpoint, model, and credentials (or reads from `.env`).
`agent_status`		Show agent name, version, model, MCP server URL, and project endpoint.
`agent_chat`	`--message "..." / -m "..."`	Start interactive multi-turn chat. Optionally pass an initial message.
`agent_destroy`	`--yes / -y`	Delete the Foundry agent. Pass `-y` to skip confirmation.

python azure_mcp_operations.py agent_create              # create agent (interactive prompts)
python azure_mcp_operations.py agent_status              # check agent info
python azure_mcp_operations.py agent_chat                # interactive chat session
python azure_mcp_operations.py agent_chat -m "list ZPA segment groups"  # chat with initial message
python azure_mcp_operations.py agent_destroy             # delete agent (confirmation prompt)
python azure_mcp_operations.py agent_destroy -y          # delete agent (no prompt)

Chat Session Features

The agent_chat command provides a full interactive CLI experience:

Animated spinner — braille-character animation (⠋ ⠙ ⠹ ...) with live elapsed-time counter while waiting for agent responses
Token tracking — per-response token usage (input, output, total) displayed after each answer
Response timing — wall-clock time for each request/response cycle
Session summary — total session duration and cumulative token count on exit
Tool approval — when the agent wants to call a Zscaler tool, you approve or reject before execution
Multi-turn — proper response chaining ensures context is maintained across follow-up questions

Example output:

  ______              _
 |___  /             | |
    / / ___  ___ __ _| | ___ _ __
   / / / __|/ __/ _` | |/ _ \ '__|
  / /__\__ \ (_| (_| | |  __/ |
 /_____|___/\___\__,_|_|\___|_|

============================================================
  Zscaler MCP Agent Chat
  Agent: zscaler-mcp-agent (v1)
  Type 'quit' or 'exit' to end the session.
============================================================

You: list all zpa segment groups
⠹ Thinking (2s)

MCP Tool Approval Requested:
  Server: zscaler
  Tool:   zpa_list_segment_groups
  Args:   {"search": null, "page": null, ...}

Approve this tool call? (y/n): y
⠸ Executing tool (3s)

Agent: Here are the ZPA segment groups currently defined: ...
       [5.2s | 1,248 tokens | in:680 out:568]

You: quit

──────────────────────────────────────────────────
Session: 38s | Total tokens: 2,496
──────────────────────────────────────────────────
[INFO]  Chat session ended.

Container Apps Deployment

▶ Walkthrough: Zscaler MCP Server and Azure Container Apps (Wistia)

Pulls the pre-built Docker image from Docker Hub (zscaler/zscaler-mcp-server:latest):

Serverless — Azure manages scaling (1-3 replicas by default)
TLS — Automatic HTTPS via Azure Container Apps ingress
No build required — image pulled directly from Docker Hub

Architecture (Container Apps)

┌──────────────────┐                           ┌──────────────────────┐
│  Claude Desktop   │     streamable-http       │   Azure Container    │
│  / Cursor         │◄─────────────────────────►│   Apps (MCP Server)  │
│  (mcp-remote)     │                           └──────────┬───────────┘
└────────┬─────────┘                                       │
         │                                                 │  Zscaler API
         ▼                                                 ▼
┌──────────────────┐    ┌────────────────┐       ┌──────────────────────┐
│  OIDC Provider   │    │  Azure Key     │       │  Zscaler Zero Trust  │
│  (if OIDCProxy)  │    │  Vault         │       │  Exchange (OneAPI)   │
└──────────────────┘    └────────────────┘       └──────────────────────┘

VM Deployment

▶ Walkthrough: Zscaler MCP Server and Azure VM (Wistia)

Provisions an Ubuntu 22.04 VM and installs the MCP server from PyPI:

Self-managed — you control the VM (SSH access, updates, etc.)
systemd service — automatic startup, restart on failure
NSG configured — SSH (22) and MCP port open

Architecture (VM)

┌──────────────────┐                           ┌──────────────────────┐
│  Claude Desktop   │     HTTP (port 8000)      │   Azure VM           │
│  / Cursor         │◄─────────────────────────►│   Ubuntu 22.04       │
│  (mcp-remote)     │                           │                      │
└────────┬─────────┘                           │  ┌────────────────┐  │
         │                                      │  │ systemd        │  │
         ▼                                      │  │ zscaler-mcp    │  │
┌──────────────────┐    ┌────────────────┐      │  └────────────────┘  │
│  OIDC Provider   │    │  Azure Key     │      └──────────┬───────────┘
│  (if OIDCProxy)  │    │  Vault         │                 │
└──────────────────┘    └────────────────┘                 │  Zscaler API
                                                           ▼
                                              ┌──────────────────────┐
                                              │  Zscaler Zero Trust  │
                                              │  Exchange (OneAPI)   │
                                              └──────────────────────┘

VM Service Management

Once deployed, you can manage the MCP server via SSH:

# SSH into the VM (or use the script)
python azure_mcp_operations.py ssh

# On the VM:
sudo systemctl status zscaler-mcp   # check status
sudo journalctl -u zscaler-mcp -f   # stream logs
sudo systemctl restart zscaler-mcp  # restart service

# Environment variables are in:
/opt/zscaler-mcp/env

# Python virtual environment:
/opt/zscaler-mcp/venv/bin/zscaler-mcp --help

AKS Deployment (Preview)

▶ Walkthrough: Zscaler MCP Server and Azure Kubernetes Service (Wistia)

Status: Preview. AKS support is fully functional for the four supported auth modes (jwt, api-key, zscaler, none) and has been validated end-to-end with cluster creation, LoadBalancer Service, and the Docker Hub image. Credentials can now be stored in Azure Key Vault and pulled at runtime via Workload Identity Federation + the Key Vault CSI driver — this is the recommended default. A simpler env-var injection path is also available for short-lived demos. OIDCProxy auth, TLS Ingress, and HPA are still planned — see Known Limitations below.

Deploys the MCP server to an Azure Kubernetes Service cluster as a Deployment exposed via a Service of type LoadBalancer:

Cluster lifecycle — create a new AKS cluster (PoC / testing) or use an existing cluster (production)
Container image — same Docker Hub image as Container Apps (zscaler/zscaler-mcp-server:latest)
External access — Azure Standard Load Balancer with public IP
Resource defaults — 200m–1000m CPU, 512Mi–1Gi memory per pod, single replica
Namespace — defaults to default, configurable
Credential storage (interactive choice):
- Azure Key Vault (default, recommended). Workload Identity Federation + Key Vault CSI driver. The script provisions the vault, the User-Assigned Managed Identity, the federated credential bound to the Pod's ServiceAccount, and the SecretProviderClass. Pods consume secrets via valueFrom.secretKeyRef against a synced Kubernetes Secret.
- Plain env vars (PoC). Credentials are baked into the Deployment manifest at deploy time — fine for short demos, not for production.
Cleanup — if you used an existing cluster, destroy removes only the K8s resources we created plus the per-deployment UAMI + federated credential (the Key Vault is preserved); if the script created the cluster, destroy deletes the entire resource group (everything goes with it).

Architecture (AKS Preview)

┌──────────────────┐                           ┌─────────────────────────────────┐
│  Claude Desktop  │     HTTP (port 80)        │   AKS Cluster                   │
│  / Cursor        │◄─────────────────────────►│                                 │
│  (mcp-remote)    │                           │  ┌───────────────────────────┐  │
└────────┬─────────┘                           │  │ Service (LoadBalancer)    │  │
         │                                      │  └─────────────┬─────────────┘  │
         ▼                                      │                │                │
┌──────────────────┐                            │  ┌─────────────▼─────────────┐  │
│  External IP     │                            │  │ Deployment                │  │
│  (Azure Std LB)  │                            │  │ zscaler-mcp-server        │  │
└──────────────────┘                            │  │ ServiceAccount + Workload │  │
                                                │  │ Identity + KV CSI driver  │  │
                                                │  │ → mounted secrets synced  │  │
                                                │  │   into K8s Secret, used   │  │
                                                │  │   via valueFrom.secretRef │  │
                                                │  └───────────────┬───────────┘  │
                                                └──────────────────┼──────────────┘
                                                                   │  Zscaler API
                                                                   ▼
                                                       ┌──────────────────────┐
                                                       │  Zscaler Zero Trust  │
                                                       │  Exchange (OneAPI)   │
                                                       └──────────────────────┘
                                                                   ▲
                                                  federated identity (OIDC)
                                                                   │
                                                       ┌──────────────────────┐
                                                       │   Azure Key Vault    │
                                                       │   (Zscaler creds)    │
                                                       └──────────────────────┘

The diagram shows the Key Vault path (default). On the env-vars path, the SecretProviderClass / ServiceAccount / Key Vault chain on the right side is omitted and the Deployment reads credentials directly from inline env values.

Prerequisites

kubectl installed (kubectl version --client) — brew install kubernetes-cli on macOS
Azure CLI with the aks-preview extension is not required (the script uses GA AKS commands)
Permission to create AKS clusters in the target resource group (Owner or Contributor)
A Standard tier subscription if creating a Standard SKU Load Balancer

Quick Start (AKS)

python azure_mcp_operations.py deploy
# When prompted, choose:
#   3) Azure Kubernetes Service (AKS) — Kubernetes deployment [PREVIEW]
#
# The script will then ask for:
#   - Azure region, resource group
#   - New cluster (default Standard_B2s, 1 node) or existing cluster name
#   - Kubernetes namespace (default: default)
#   - Container image (default: zscaler/zscaler-mcp-server:latest)
#   - MCP server port (default: 8000)

What the Script Does

Verifies kubectl and az are installed and the user is logged in
Creates the resource group if it does not exist
Creates a new AKS cluster (managed identity + Standard load balancer; on the Key Vault path also --enable-workload-identity --enable-oidc-issuer --enable-addons azure-keyvault-secrets-provider) or verifies the existing cluster (and enables workload identity + KV CSI addon retroactively if needed)
Runs az aks get-credentials to set the kubectl context
Creates the namespace if needed
Key Vault path only: provisions / verifies the Key Vault, stores every Zscaler secret in it, creates the User-Assigned Managed Identity, grants it Key Vault Secrets User, and creates the federated credential bridging the K8s ServiceAccount to the UAMI
Generates .aks-manifest.yaml — Deployment + Service for the env-vars path; ServiceAccount + SecretProviderClass + Deployment (with valueFrom.secretKeyRef) + Service for the Key Vault path
Applies the manifest with kubectl apply
Polls for the LoadBalancer external IP (up to 5 minutes)
Updates Claude Desktop / Cursor configs with http://<EXTERNAL_IP>/mcp

Operations on AKS

# Status — shows AKS provisioning state, pod, and service
python azure_mcp_operations.py status

# Stream pod logs (kubectl logs deployment/zscaler-mcp-server -n <ns> -f)
python azure_mcp_operations.py logs

# Destroy
#   - If you created a new cluster: deletes the entire resource group
#   - If you used an existing cluster: deletes only the K8s Deployment + Service
python azure_mcp_operations.py destroy

Direct kubectl

After deployment, the kubectl context is set to your AKS cluster. You can use kubectl directly:

kubectl get pods -n default -l app=zscaler-mcp-server
kubectl logs deployment/zscaler-mcp-server -n default -f
kubectl get svc zscaler-mcp-server -n default
kubectl describe deployment zscaler-mcp-server -n default

Known Limitations (Preview)

OIDCProxy auth mode is not supported on AKS today — use jwt, api-key, zscaler, or none
No Ingress controller — the script provisions a LoadBalancer Service that exposes plain HTTP on port 80. For production, place this behind Application Gateway / NGINX Ingress with cert-manager for TLS (requires a DNS A record pointing at the cluster's ingress LoadBalancer).
Single replica by default — for HA, edit .aks-manifest.yaml and re-apply, or scale via kubectl scale deployment zscaler-mcp-server --replicas=3.

Azure AI Foundry Agent Integration

▶ Walkthrough: Zscaler MCP Server and Azure AI Foundry Agent (Wistia)

For organizations using Azure AI Foundry, you can create a managed AI agent that uses your deployed MCP server as a tool. This enables:

Azure-hosted AI agent — no need to run Claude Desktop or Cursor
REST API access — integrate Zscaler AI into your applications
Microsoft 365 Copilot integration — publish to Teams and Copilot
Centralized management — manage agents through Azure portal

Architecture (Foundry Agent)

┌──────────────────────────────────────────────────────────────────────────┐
│                         Azure Subscription                               │
│                                                                          │
│  ┌──────────────────────────┐       ┌──────────────────────────────┐    │
│  │  Azure Container Apps    │       │  Azure AI Foundry             │    │
│  │  or VM                   │◄─────│  (Agent Service)              │    │
│  │                          │       │                              │    │
│  │  ┌────────────────────┐  │       │  McpTool(                    │    │
│  │  │ zscaler-mcp-server │  │       │    server_label="zscaler",   │    │
│  │  │ (streamable-http)  │  │       │    server_url="http://...",  │    │
│  │  └────────────────────┘  │       │    headers={X-Zscaler-*},    │    │
│  └──────────────────────────┘       │    require_approval="always" │    │
│                                     │  )                           │    │
│              │                      │                              │    │
│  ┌───────────▼──────────┐           │  ┌────────────────────────┐  │    │
│  │  Azure Key Vault     │           │  │  Azure OpenAI          │  │    │
│  │  (Zscaler secrets)   │           │  │  (GPT-4o / GPT-4)     │  │    │
│  └──────────────────────┘           │  └────────────────────────┘  │    │
│                                     └──────────────────────────────┘    │
└──────────────────────────────────────────────────────────────────────────┘
                    │                            │
                    ▼                            ▼
          Zscaler Zero Trust              User Applications
          Exchange APIs                   (Portal, API, Copilot)

Prerequisites for Foundry Agent

Azure AI Foundry project — create at ai.azure.com
Azure OpenAI deployment — GPT-4o or GPT-4 model
Deployed MCP server — Container Apps or VM (from this script)
Python packages: pip install azure-ai-projects azure-identity
Azure CLI authenticated: az login

Quick Start (Foundry Agent)

# 1. Deploy MCP server first (if not already done)
python azure_mcp_operations.py deploy

# 2. Create the Foundry "Custom keys" connection ONE TIME in the portal
#    (see "MCP Server Authentication from Foundry" below for the exact steps).

# 3. Create Foundry agent
python azure_mcp_operations.py agent_create
# You'll be prompted for:
#   - Foundry project endpoint (from portal → Project Overview)
#   - Model deployment name (default: gpt-4o)
#   - Foundry connection name that holds the auth headers
#     (default: zscaler-mcp-headers — pin via AZURE_FOUNDRY_CONNECTION_NAME)
#   - MCP server auth credentials (loaded from .env or entered manually)

# 4. Start interactive chat (CLI)
python azure_mcp_operations.py agent_chat

# 5. Or check agent status
python azure_mcp_operations.py agent_status

# 6. Delete agent when done
python azure_mcp_operations.py agent_destroy

MCP Server Authentication from Foundry

Foundry no longer accepts auth headers inlined in MCPTool.headers — any header containing words like secret, key, token, or authorization is rejected with invalid_payload. The supported pattern is to register a Custom keys connection in the project that holds the headers and reference it via MCPTool.project_connection_id. Foundry injects the connection's keys as request headers when calling the MCP server.

One-time portal setup:

Open your project at ai.azure.com.
Left nav → Management center → Connected resources.
+ New connection → Custom keys.
Name the connection (default expected by the script: zscaler-mcp-headers).
Mark each entry as a secret and add the rows below for your MCP auth mode:

MCP Auth Mode	Custom Keys to Add	Source
`zscaler`	`X-Zscaler-Client-ID` + `X-Zscaler-Client-Secret`	OneAPI credentials
`api-key`	`X-MCP-API-Key`	MCP API key
`none`	(no connection needed)	—

Save, then run agent_create.

The connection name is read from AZURE_FOUNDRY_CONNECTION_NAME (env var or .env), defaulting to zscaler-mcp-headers. The data-plane SDK (azure-ai-projects v2.0.x) cannot create connections — only read them — so the portal step is currently required. Connection CRUD via the management plane is on the follow-up roadmap.

Why the change? The previous build inlined the headers via MCPTool.headers. Microsoft has since tightened the denylist on sensitive header names, so that path now returns Headers that can include sensitive information are not allowed in the headers property for MCP tools. Use project_connection_id instead. The error is the prompt for this refactor.

Foundry Portal (UI)

After creating the agent, you can access it through the Azure AI Foundry portal:

Go to ai.azure.com and open your project.
Make sure the "New Foundry" toggle (top-right of the page) is ON — Prompt Agents are surfaced only in the new experience.
Left nav: Build → Agents → Agents tab.
Select zscaler-mcp-agent (Type column will show prompt, Version 1).
Use the Playground to test the agent interactively.

The script's agent_create command also prints a deep link to the agent at the end of a successful run.

Two agent surfaces in Foundry — heads-up. The "Agents" view in the new Foundry experience lists Prompt Agents (created by this script, type prompt, with versioning). The classic experience also has an "Agents" tab that lists Assistant API agents (type asst_xxxx, no versioning). They are different platforms in the same project. If you previously opened the Playground or used another tool, you may see leftover Agent### rows in classic — they're unrelated to zscaler-mcp-agent and safe to delete from View classic agents in the new UI's banner.

The portal also lets you publish, monitor, and manage agent versions.

Publishing Agents

Foundry agents can be published to different scopes:

Scope	Visibility	Admin Approval	Best For
Individual	Only you (shareable via link)	Not required	Testing, pilots
Organization	Everyone in Azure AD tenant	Required (your IT admin)	Production

Publication is self-service — no Microsoft involvement required. Publish through the Foundry portal or programmatically via the SDK.

Tool Approval

The Foundry agent is configured with require_approval="always" by default. When the agent wants to use a Zscaler tool:

The agent describes what tool it wants to call and why
You approve or reject the tool call
If approved, the tool executes and returns results
The agent processes results and continues

This ensures human oversight for all Zscaler operations.

Credential Sources

From a `.env` file

Copy env.properties to .env and fill in the values. During deployment, select "From a .env file" and provide the file path.

Interactive prompts

Select "Enter manually" and the script will prompt for each credential. Secrets are entered via getpass (hidden input).

Azure Key Vault

All secrets are stored in Azure Key Vault (mandatory). During deployment you can:

Create a new vault — the script handles creation, RBAC, and secret storage
Use an existing vault — provide the vault name

Stored secrets include Zscaler API credentials and auth-mode-specific credentials.

Environment Variables

Zscaler API (required for all modes)

Variable	Description
`ZSCALER_CLIENT_ID`	OneAPI client ID from ZIdentity
`ZSCALER_CLIENT_SECRET`	OneAPI client secret
`ZSCALER_VANITY_DOMAIN`	Zscaler vanity domain
`ZSCALER_CUSTOMER_ID`	Zscaler customer ID
`ZSCALER_CLOUD`	Zscaler cloud (e.g. `production`, `beta`)

OIDCProxy Mode

Variable	Description
`OIDCPROXY_DOMAIN`	OIDC provider domain (e.g. `login.microsoftonline.com/<tenant>/v2.0` or `tenant.auth0.com`)
`OIDCPROXY_CLIENT_ID`	Application / client ID from your identity provider
`OIDCPROXY_CLIENT_SECRET`	Client secret from your identity provider
`OIDCPROXY_AUDIENCE`	Token audience / API identifier (default: `zscaler-mcp-server`)

JWT Mode

Variable	Description
`ZSCALER_MCP_AUTH_JWKS_URI`	JWKS endpoint URL
`ZSCALER_MCP_AUTH_ISSUER`	Expected JWT issuer
`ZSCALER_MCP_AUTH_AUDIENCE`	Expected JWT audience (default: `zscaler-mcp-server`)

API Key Mode

Variable	Description
`ZSCALER_MCP_AUTH_API_KEY`	Shared API key (auto-generated if omitted)

MCP Server Options

Variable	Default	Description
`MCP_PORT`	`8000`	Server listen port
`ZSCALER_MCP_DISABLED_SERVICES`	(none)	Comma-separated services to disable
`ZSCALER_MCP_DISABLED_TOOLS`	(none)	Comma-separated tool patterns to disable
`ZSCALER_MCP_WRITE_ENABLED`	`false`	Enable write tools
`ZSCALER_MCP_WRITE_TOOLS`	(none)	Comma-separated write tool patterns to allow

Client Configuration

After deployment, the script automatically updates your Claude Desktop and Cursor configs. If you need to configure manually, use the examples below.

Claude Desktop (`claude_desktop_config.json`)

Location:

macOS: ~/Library/Application Support/Claude/claude_desktop_config.json
Windows: %APPDATA%\Claude\claude_desktop_config.json
Linux: ~/.config/Claude/claude_desktop_config.json

API Key / Zscaler Auth Mode:

{
  "mcpServers": {
    "zscaler-mcp-server": {
      "command": "npx",
      "args": [
        "-y",
        "mcp-remote",
        "http://<PUBLIC_IP>:8000/mcp",
        "--allow-http",
        "--header",
        "Authorization:Bearer <API_KEY>"
      ]
    }
  }
}

For Zscaler auth mode, use Authorization:Basic <base64(client_id:client_secret)>.

OIDCProxy Mode (browser login):

{
  "mcpServers": {
    "zscaler-mcp-server": {
      "command": "npx",
      "args": [
        "-y",
        "mcp-remote",
        "http://<PUBLIC_IP>:8000/mcp",
        "--allow-http"
      ]
    }
  }
}

No --header needed — mcp-remote handles the OAuth flow automatically.

JWT Mode:

{
  "mcpServers": {
    "zscaler-mcp-server": {
      "command": "npx",
      "args": [
        "-y",
        "mcp-remote",
        "http://<PUBLIC_IP>:8000/mcp",
        "--allow-http",
        "--header",
        "Authorization:Bearer <YOUR_JWT_TOKEN>"
      ]
    }
  }
}

No Auth Mode:

{
  "mcpServers": {
    "zscaler-mcp-server": {
      "command": "npx",
      "args": [
        "-y",
        "mcp-remote",
        "http://<PUBLIC_IP>:8000/mcp",
        "--allow-http"
      ]
    }
  }
}

Note: The --allow-http flag is required when connecting to a non-localhost HTTP URL. For HTTPS endpoints (Container Apps with TLS), you can omit this flag.

Cursor (`mcp.json`)

Location:

macOS/Linux: ~/.cursor/mcp.json
Windows: %USERPROFILE%\.cursor\mcp.json

API Key / Zscaler Auth Mode:

{
  "mcpServers": {
    "zscaler-mcp-server": {
      "url": "http://<PUBLIC_IP>:8000/mcp",
      "headers": {
        "Authorization": "Bearer <API_KEY>"
      }
    }
  }
}

OIDCProxy / JWT / No Auth:

{
  "mcpServers": {
    "zscaler-mcp-server": {
      "url": "http://<PUBLIC_IP>:8000/mcp"
    }
  }
}

For JWT, add the headers block with your token.

Windows Configuration

On Windows, use cmd as the command wrapper:

{
  "mcpServers": {
    "zscaler-mcp-server": {
      "command": "cmd",
      "args": [
        "/c",
        "npx",
        "-y",
        "mcp-remote",
        "http://<PUBLIC_IP>:8000/mcp",
        "--allow-http",
        "--header",
        "Authorization:Bearer <API_KEY>"
      ]
    }
  }
}

Troubleshooting

"Non-HTTPS URLs are only allowed for localhost"

If Claude Desktop shows this error:

Error: Non-HTTPS URLs are only allowed for localhost or when --allow-http flag is provided

Add --allow-http to your mcp-remote args (see examples above). The deployment script adds this automatically for HTTP endpoints.

Claude Desktop shows "Server disconnected"

Check VM/Container status: python azure_mcp_operations.py status
View logs: python azure_mcp_operations.py logs
Verify the MCP URL is reachable: curl http://<PUBLIC_IP>:8000/mcp
Ensure NSG allows traffic on port 8000

VM service not running

SSH into the VM and check the service:

python azure_mcp_operations.py ssh

# On the VM:
sudo systemctl status zscaler-mcp
sudo journalctl -u zscaler-mcp -n 50

OIDCProxy callback URL issues

For OIDCProxy mode, ensure the callback URL is registered in your identity provider (Entra ID, Okta, Auth0, etc.):

http://<PUBLIC_IP>:8000/auth/callback

Some providers may require explicitly allowing HTTP callback URLs in their settings for non-HTTPS deployments.

Security

Secrets in Key Vault: All credentials stored in Azure Key Vault (mandatory)
Five auth modes: Choose the authentication level appropriate for your environment
TLS: Container Apps provides automatic HTTPS; VM deployments use HTTP by default
NSG: VM deployments configure Network Security Group rules for SSH and MCP port
HMAC confirmations: Destructive operations require cryptographic confirmation tokens
Read-only by default: Write tools are disabled unless explicitly enabled

Video Walkthrough​

Deployment Targets​

What It Does​

Authentication Modes​

Prerequisites​

Quick Start​

Operations​

MCP Server Operations​

Foundry Agent Operations​

Chat Session Features​

Container Apps Deployment​

Architecture (Container Apps)​

VM Deployment​

Architecture (VM)​

VM Service Management​

AKS Deployment (Preview)​

Architecture (AKS Preview)​

Prerequisites​

Quick Start (AKS)​

What the Script Does​

Operations on AKS​

Direct kubectl​

Known Limitations (Preview)​

Azure AI Foundry Agent Integration​

Architecture (Foundry Agent)​

Prerequisites for Foundry Agent​

Quick Start (Foundry Agent)​

MCP Server Authentication from Foundry​

Foundry Portal (UI)​

Publishing Agents​

Tool Approval​

Credential Sources​

From a .env file​

Interactive prompts​

Azure Key Vault​

Environment Variables​

Zscaler API (required for all modes)​

OIDCProxy Mode​

JWT Mode​

API Key Mode​

MCP Server Options​

Client Configuration​

Claude Desktop (claude_desktop_config.json)​

Cursor (mcp.json)​

Windows Configuration​

Troubleshooting​

"Non-HTTPS URLs are only allowed for localhost"​

Claude Desktop shows "Server disconnected"​

VM service not running​

OIDCProxy callback URL issues​

Security​

Video Walkthrough

Deployment Targets

What It Does

Authentication Modes

Prerequisites

Quick Start

Operations

MCP Server Operations

Foundry Agent Operations

Chat Session Features

Container Apps Deployment

Architecture (Container Apps)

VM Deployment

Architecture (VM)

VM Service Management

AKS Deployment (Preview)

Architecture (AKS Preview)

Prerequisites

Quick Start (AKS)

What the Script Does

Operations on AKS

Direct kubectl

Known Limitations (Preview)

Azure AI Foundry Agent Integration

Architecture (Foundry Agent)

Prerequisites for Foundry Agent

Quick Start (Foundry Agent)

MCP Server Authentication from Foundry

Foundry Portal (UI)

Publishing Agents

Tool Approval

Credential Sources

From a `.env` file

Interactive prompts

Azure Key Vault

Environment Variables

Zscaler API (required for all modes)

OIDCProxy Mode

JWT Mode

API Key Mode

MCP Server Options

Client Configuration

Claude Desktop (`claude_desktop_config.json`)

Cursor (`mcp.json`)

Windows Configuration

Troubleshooting

"Non-HTTPS URLs are only allowed for localhost"

Claude Desktop shows "Server disconnected"

VM service not running

OIDCProxy callback URL issues

Security
